LevelOne 16-Port Fast Ethernet PoE Switch, 90W – photo 1

LevelOne 16-Port Fast Ethernet PoE Switch, 90W – photo 2

Out of Stock / Please Enquire ETA

LEVELONE

LevelOne 16-Port Fast Ethernet PoE Switch, 90W

R3,878

incl. VAT: R4,460

Stock: Out of Stock / Please Enquire ETA
Brand: LEVELONE
Model: FEP-1600W90
EAN: 4015867199831
Product code: 413992

LEVELONE

Please Inquire

R3,878 incl. VAT: R4,460

We will email you when the product is back in stock.

Key features

Basic switching RJ-45 Ethernet ports quantity: 16
10BASE-T, 100BASE-TX
MAC address table: 4000 entries Switching capacity: 3.2 Gbit/s
Power over Ethernet (PoE)

Tags: levelone switches , levelone switche

Description
Specifications

FEP-1600 is a 16-port 10/100Mbps Fast Ethernet Switch with Power over Ethernet (PoE) capability. With 16 dip switches, each PoE port can be manually set for On-Off control. FEP-1600 supports up to 30W on each LAN port when the DIP switch is in the ON position . Using a LevelOne PoE repeater, it is possible to extend the connection a further 100 meters, or even daisy-chain several PoE repeaters together for greater distances. Dual 10/100Mbps ports can connect with other edge switches or NVR as uplink ports.

- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- 10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX
- PoE on/off control per port by dip switches
- Simple Plug and Play installation

Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
Network
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-TX
Full duplex	Yes
Flow control support	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
Data transmission
MAC address table	4000 entries
Switching capacity	3.2 Gbit/s
Store-and-forward	Yes
Packet forwarding rate (100 Mbps)	148000 pps
Packet forwarding rate (10 Mbps)	14880 pps
Design
Product colour	Grey
LED indicators	Activity, PoE, Power
Wall mountable	Yes
On/off switch	Yes
Performance
Buffer size	160 KB
Plug and Play	Yes
Power
DC input voltage	56 V
Power consumption (typical)	90 W
Power over Ethernet (PoE)
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	82 W
Operational conditions
Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 90%
Weight & dimensions
Width	188 mm
Depth	118 mm
Height	38 mm
Weight	2.1 kg
Packaging content
Cables included	AC
Manual	Yes
Packaging data
AC adapter included	Yes
Package type	Box
Package width	534 mm
Package depth	255 mm
Package height	95 mm
Package weight	2.5 kg
Certificates
Certification	FCC, CE, RoHS
Logistics data
Country of origin	Taiwan
Master (outer) case width	555 mm
Master (outer) case length	510 mm
Master (outer) case height	280 mm
Harmonized System (HS) code	85176990
Master (outer) case gross weight	13.5 kg
Products per master (outer) case	5 pc(s)
