Wireless Device TP-LINK 300 Mbit/s 2xLAN ports CPE210

TP-Link’s 2.4GHz 300Mbps 9dBi Outdoor CPE, the CPE210 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE210 an ideal choice for both business and home users.

Enterprise Hardware

With Qualcomm Atheros level chipsets, high gain antennas and high
quality material, specially designed enclosure, and PoE power supply, CPE210 is
specially designed for outdoor use and can operate flawlessly in almost any climate,
with operating temperatures ranging from -40℃ (-40℉) to +70℃ (158℉).


Advanced Antenna System

Built-in High Gain Dual-Polarized Antenna
Dedicated metal reflector ensures higher gain and lower noise interference

5km+ Wireless Data Transmission

Specially designed for outdoor uses, ideal for long distance wireless data transmission over 5km+, tested in the field.

TP-Link MAXtream TDMA Technology

As network scale increases, wireless competition and collisions among CPEs and base stations will be
so enormous that the real throughput of the network will drop, resulting in a serious impact on end-user
experience. To mitigate these effects, the CPE210 uses MAXtream TDMA Technology.

Pharos Control – Centralized Management System

CPE210 also comes equipped with centralized management software that helps users easily
manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery,
status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.

• Built-in 9dBi 2x2 dual-polarized directional MIMO antenna
• Adjustable transmission power from 0 to 27dBm/500mw
• System-level optimizations for more than 5km long range wireless transmission
• TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
• Centralized Management System – Pharos Control
• AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes
• Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely

Summary: TP-Link CPE210. 2.4 GHz, Maximum data transfer rate: 300 Mbit/s. Security algorithms: AES, TKIP, WPA, WPA-PSK, WPA2, WPA2-PSK. Power over Ethernet (PoE). Product colour: White | Vendor Homepage: https://www.tp-link.com/pk/business-networking/outdoor-radio/cpe210/v3.20/ | 2.4 GHz: Yes | 5 GHz: No | 6 GHz: No | Maximum data transfer rate: 300 | Frequency band: 2.4 - 2.483 | Networking standards: IEEE 802.11b/IEEE 802.11g/IEEE 802.11n | Automatic channel scanning: Yes | Automatic channel selection: Yes | MIMO: Yes | VLAN support: Yes | Wireless isolation: Yes | Dynamic Frequency Selection (DFS): Yes | Maximum outdoor range: 5000 | Security algorithms: AES/TKIP/WPA/WPA2/WPA2-PSK/WPA-PSK | MAC address filtering: Yes | Service Set Identifier (SSID) features: SSID broadcast/SSID broadcast on/off | IGMP snooping: Yes | Auto Wireless Distribution System (WDS): Yes | Universal Plug and Play (UPnP): Yes | Web-based management: Yes | Management platform: Pharos Control | Firmware upgradeable: Yes | Ethernet LAN (RJ-45) ports: 2 | DC-in jack: Yes | Power over Ethernet (PoE): Yes | Power over Ethernet (PoE) type supported: Passive PoE | AC input frequency: 50 - 60 | AC input voltage: 100 - 240 | Output voltage: 24 | Output current: 0.25 | Placement: Pole | Product colour: White | International Protection (IP) code: IPX5 | Reset button: Yes | LED indicators: Status | Antenna type: Internal | Antenna direction type: Directional | Antenna gain level (max): 9 | Polarization: Dual polarization | Built-in processor: Yes | Processor model: Qualcomm Atheros | Processor frequency: 560 | Processor architecture: MIPS 74Kc | Flash memory: 8 | Internal memory: 64 | Certification: CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark CE, FCC, RoHS | Width: 224 | Depth: 79 | Height: 60 | Package width: 132 | Package depth: 270 | Package height: 106 | Package weight: 760 | Quantity per pack: 1 | Cables included: AC | Mounting kit: Yes | Operating relative humidity (H-H): 10 - 90 | Operating temperature (T-T): -30 - 70 | Storage temperature (T-T): -40 - 70 | Storage relative humidity (H-H): 5 - 95 | Unit Calculated Weight: 0.745 | Product Net Weight: 0.34 | Unit Calculated Volume: 0.003685 | Units per Shipping Box: 1 | Unit Width: 13 | Units per Pallet: 0 | Shipping Box Height: 10.5 | Unit Depth: 27 | Unit Height: 10.5 | Name: WRL CPE OUTDOOR 300MBPS/CPE210 TP-LINK | Model name: CPE210
