Switch AXIS D8004 1x10Base-T 100Base-TX 1xRJ45 02101-002

The palm-sized AXIS D8004 Unmanaged PoE Switch delivers network and power for up to 4 network devices with plug and play installation. Using AXIS D8004 Unmanaged PoE Switch as a central power source simplifies both installation and maintenance. The switch, together with AXIS surveillance cards, is perfect for small systems with few devices and basic video storage requirements. AXIS D8004 Unmanaged PoE Switch is also ideal when it’s not possible to pull multiple cables. If there’s local power available, simply pull one cable with data connection from the core switch or router, and AXIS D8004 Unmanaged PoE Switch can provide Power over Ethernet (PoE) for all 4 products.

• 4-port 10/100 Mbps 802.3af/at PoE+; 60 W PoE power budget; Level VI energy efficiency compliance; Palm-sized, metal casing; Plug and play installation

Summary: Axis 02101-002. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100), Basic switching RJ-45 Ethernet ports quantity: 4. Networking standards: IEEE 802.3af, IEEE 802.3at. Power connector: DC-in jack. Power over Ethernet (PoE) | Vendor Homepage: https://www.axis.com/ | Switch type: Unmanaged | Basic switching RJ-45 Ethernet ports quantity: 4 | Basic switching RJ-45 Ethernet ports type: Fast Ethernet (10/100) | Power connector: DC-in jack | Networking standards: IEEE 802.3af/IEEE 802.3at | 10G support: No | Ethernet LAN data rates: 10,100 | Product colour: White | Housing material: Metal | LED indicators: Activity/Network/PoE/Power | Power supply included: Yes | AC input voltage: 100 - 240 | AC input frequency: 50 - 60 | Power consumption (max): 62 | Power over Ethernet (PoE): Yes | Power over Ethernet plus (PoE+) ports quantity: 4 | Power over Ethernet (PoE) power per port: 30 | Total Power over Ethernet (PoE) budget: 60 | Operating temperature (T-T): 0 - 50 | Storage temperature (T-T): -10 - 50 | Operating relative humidity (H-H): 5 - 95 | Storage relative humidity (H-H): 5 - 95 | Width: 90 | Depth: 80 | Height: 21 | Weight: 172 | Cables included: AC | User guide: Yes | Certification: EN 55022:2010/55032:2012 + AC : 2013 Class B, EN 55024, EN 61000-3-2, EN 61000-3-3, EN 50581, FCC Part 15 Subpart B Class B, ICES-003 Class B, IEC/EN/UL 60950-1, CE, WEEE, C-Tick/RCM | Harmonized System (HS) code: 85176990 | Unit Calculated Weight: 0.857 | Product Net Weight: 0.172 | Unit Calculated Volume: 0.002368 | Units per Shipping Box: 1 | Shipping Box Height: 15.5 | Name: NET SWITCH 4PORT POE+ D8004/02101-002 AXIS | Model name: D8004
