✅ In Stock

DELL

DELL R570 server 1.92 TB Rack (2U) Intel Xeon 6 6517P 3.2 GHz 32 GB DDR5-SDRAM 1100 W

R207,917

incl. VAT: R239,104

Stock: Backordered - delivers in 10-15 days
Brand: DELL
Model: RCYKN
EAN: 5397184980538
Product code: 613474

Backordered goods Delivery in 10–15 working days

Available Options

Warranty extension

R207,917 incl. VAT: R239,104

Qty

Save PDF

Key features

No OS
Intel Xeon 6 6517P (72MB Cache, 3.2GHz)
32GB DDR5-SDRAM (1 x 32) & 1920GB SSD
iDRAC10, Enterprise 17G

Tags: dell servers , dell server

Description
Specifications

Simple, Scalable and Efficient Solutions

The Dell PowerEdge R570 is a 2U, one-socket rack server engineered for high-performance computing with exceptional power efficiency and balanced performance, driving cost savings and boosting data center productivity.

Processor
Processor family	Intel Xeon 6
Processor manufacturer	Intel
Processor model	6517P
Processor frequency	3.2 GHz
Processor boost frequency	4.2 GHz
Processor cores	16
Processor cache	72 MB
Number of processors installed	1
Thermal Design Power (TDP)	190 W
System bus rate	24 GT/s
Processor threads	32
Memory types supported by processor	DDR5-SDRAM
Memory clock speeds supported by processor	6400 MHz
Memory
Internal memory	32 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	1 TB
Buffered memory type	Registered (buffered)
Memory ranking	2
Memory slots	16x DIMM
Memory layout (slots x size)	1 x 32 GB
Memory data transfer rate	6400 MT/s
Storage
Total storage capacity	1.92 TB
RAID support	Yes
Optical drive type	No
Number of SSDs installed	2
SSD capacity	960 GB
SSD interface	SATA III
SSD size	2.5"
Supported SSD sizes	2.5"
Number of SSDs supported	16
Supported RAID controllers	PERC H965i Controller, Front, DC-MHS
Hot-Plug support	Yes
Drive writes per day (DWPD)	1
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
VGA (D-Sub) ports quantity	1
Expansion slots
PCI Express x16 (Gen 5.x) slots	2
Design
Chassis type	Rack (2U)
Product colour	Black
Bezel	Yes
Performance
Remote administration	iDRAC10, Enterprise 17G
Software
Operating system installed	No
Compatible operating systems	Canonical Ubuntu Server LTS RedHat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi Windows Server Windows Server Datacenter
Power
Redundant power supply (RPS) support	Yes
Power supply	1100 W
Number of redundant power supplies installed	2
Power supply input voltage	100 - 240 V
Certificates
80 PLUS certification	80 PLUS Titanium
Carbon footprint
Total carbon footprint (kg of CO2e)	1247
Total carbon emissions, standard deviation (kg of CO2e)	101
Carbon emissions, manufacturing (kg of CO2e)	463.88
Carbon emissions, logistics (kg of CO2e)	209.5
Carbon emissions, energy usage (kg of CO2e)	537.46
Carbon emissions, end-of-life (kg of CO2e)	37.41
PAIA version	PAIA 1.4.7, 2025
Weight & dimensions
Width	482 mm
Height	86.8 mm
Packaging content
Packaging content	2x Rack Power Cord 2M (C13/C14 12A) - FGA Only 2U Combo Drop-In/Stab-In Rails,Riser Config 5
Other features
Data transfer rate	6 Gbit/s
Bytes per sector	512e
Target workload	Read Intensive (RI)
Open Compute Project (OCP)	1x16 FLOP, 1x16 Onboard, 1 Rear Blank
