✅ In Stock

TP-LINK

TP-Link Omada 300Mbps Wireless N Wall-Plate Access Point

R1,439

incl. VAT: R1,655

Stock: Backordered - delivers in 10-15 days
Brand: TP-LINK
Model: EAP115-WALL
Weight: 0.2 kg
Dimensions: 9 × 9 × 3 cm
EAN: 6935364093457
Product code: 413413

TP-LINK

Backordered goods Delivery in 10–15 working days

Available Options

Warranty extension

R1,439 incl. VAT: R1,655

Qty

Save PDF

Key features

Easy-mount construction allows installation into any standard EU-type data wall-box
Compact, low-profile design fits discreetly with any existing interior style
Free Auranet Controller Software enables administrators to easily manage hundreds of EAPs
Support Power over Ethernet (802.3af) for convenient and affordable installation
Enterprise class Wi-Fi security helps to decrease network security threats
Captive portal provides one convenient method of authentication for Wi-Fi guests
Supports management vlan for an enhanced network management

Tags: tp-link wifi access points , tp-link wifi access point

Description
Specifications

Installation Made Easy

- Detach the faceplate of the junction box* with a screwdriver.
- Remove the faceplate of the EAP.
- Connect an in-wall Ethernet cable to the Uplink+POE port.
- Secure the access point to the wall using the nails provided.
- Press the faceplate back into position.

Perfectly Formed

The EAP115-Wall would blend seamlessly into any business setting with a refined, minimalist appearance. A slimline design includes casing that’s just 11 mm in thickness.

Effortless Deployment

With 802.3af Power over Ethernet supported there’s no need for additional wiring. Simply plug in existing Ethernet cables and you’re ready to go.

Complete Wireless Coverage

An EAP in each room guarantees a strong wireless signal and allows guests to enjoy their own private Wi-Fi network.

Cloud Centralized Management
- Anytime, Anywhere
Omada Cloud Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.

Easy Management with the Omada App

Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.

Features
2.4 GHz	Yes
5 GHz	No
6 GHz	No
Maximum data transfer rate	300 Mbit/s
Maximum data transfer rate (2.4 GHz)	300 Mbit/s
Ethernet LAN data rates	10,100 Mbit/s
Frequency band	2.4 - 2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Cabling technology	10/100Base-T(X)
Automatic channel selection	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
VLAN support	Yes
Virtual LAN features	Port-based VLAN, VLAN mapping
Rate limiting	Yes
Wireless isolation	Yes
Quality of Service (QoS) support	Yes
Transmitting power (CE)	20 dBm
Transmitting power	15 dBmW
Security
Security algorithms	802.1x RADIUS, HTTPS, WPA, WPA-PSK, WPA2, WPA2-PSK
MAC address filtering	Yes
Service Set Identifier (SSID) features	Multiple SSIDs
Number of SSID supported	8
Access Control List (ACL)	Yes
Protocols
Management protocols	SNMP, Telnet
Management features
Web-based management	Yes
Syslog	Yes
Ports & interfaces
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	0
WAN connection	Ethernet (RJ-45)
Power
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	Passive PoE
Power consumption (typical)	2.8 W
Design
Placement	Wall
Product colour	White
Cable lock slot	No
Reset button	Yes
LED indicators	Yes
Internal	No
Antenna
Antenna type	Internal
Antenna direction type	Omni-directional
Antenna features	Integrated antenna
Antennas quantity	2
Antenna gain level (max)	1.8 dBi
Performance
Compatible operating systems	Windows XP, Windows Vista, Windows 7, Windows 8, Windows 10
Certificates
Compliance certificates	CE, RoHS
Weight & dimensions
Width	86.8 mm
Depth	86.8 mm
Height	30.2 mm
Packaging data
Package width	118 mm
Package depth	130 mm
Package height	47 mm
Package weight	190 g
Packaging content
Quantity per pack	1 pc(s)
Mounting kit	Yes
Quick start guide	Yes
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 90%
Logistics data
Harmonized System (HS) code	85176990
Sustainability
Sustainability compliance	Yes
