LevelOne 28-Port L2 Plus Managed PoE Industrial Switch, 4 x 1/2.5/10GbE SFP+, 24 PoE Outputs, 370W, 802.3AF/AT/BT PoE, 19" Rack Mount, -40°C to 80°C

LevelOne 28-Port L2 Plus Managed PoE Industrial Switch, 4 x 1/2.5/10GbE SFP+, 24 PoE Outputs, 370W, 802.3AF/AT/BT PoE, 19
Out of Stock / Please Enquire ETA


Please Inquire

💡Note: Delivery time is calculated from the moment your order is confirmed and is approximate. For a more precise estimate,
LevelOne 28-Port L2 Plus Managed PoE Industrial Switch, 4 x 1/2.5/10GbE SFP+, 24 PoE Outputs, 370W, 802.3AF/AT/BT PoE, 19" Rack Mount, -40°C to 80°C
incl. VAT: R32,374
R28,151
  • Stock: Out of Stock / Please Enquire ETA
  • Brand: LEVELONE
  • Model: IXP-2871
  • EAN: 4015867240694
  • Warranty: 1 year
LEVELONE
Add to Cart
Buy Now Question?
Add to Wish List Compare this Product
 PDF Google

Key features

  • 24 10/100/1000Base-T RJ45 PoE ports and 4 1G/2.5G/10GBase-X SFP+ slots
  • Total PoE power budget: 370W, up to 90W per port (Ports 1~2 90W per port, Ports 3~24 30W per port)
  • IEEE 802.3af/at/bt PoE compliant to simplify deployment and installation
  • Ensures uninterrupted operation with redundant DC power supply, advanced surge protection (6KV), and ESD protection (Air-15kV, Contact-8kV)
  • Delivers high availability through G.8032 ERPS protocol with <20ms recovery time
  • Supports advanced Layer 2 features including VLAN, STP/RSTP/MSTP, Link Aggregation, QoS, and IGMP Snooping for optimized network performance
  • Offers robust management options through Web, SNMP, CLI, Telnet, and SSH interfaces
  • Provides enhanced security with 802.1X authentication, port isolation, and ACL
  • Enables advanced network routing with IPv4/IPv6 static routing and DHCP server
  • Designed for harsh environments with fanless IP40 rack-mount enclosure and wide operating temperature range (-40°C to +80°C)
Tags: levelone switches , levelone switche
The IXP-2871 is a high-performance industrial Ethernet switch with 24 PoE ports and 4 SFP+ slots. It delivers up to 370W of PoE power, with Ports 1-2 supporting up to 90W and Ports 3-24 supporting up to 30W, providing flexibility in power allocation for various powered devices. Designed to excel in industrial automation, it offers comprehensive Layer 2 management and rapid failover capabilities. This switch ensures uninterrupted operations with its ERPS redundant network, boasting a sub-20ms recovery time. Its wide operating temperature range, DC Redundant power supply, and fanless design ensure uninterrupted operation in harsh industrial conditions. Ideal for large-scale industrial networks.
Specifications
Warehouse group Server/Storage/Network > Switche [+1434][-907]
Management features
Switch type Managed
Switch layer L2+
Quality of Service (QoS) support Yes
Web-based management Yes
ARP inspection Yes
Configuring Location Settings (CLI) Yes
System event log Yes
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity 24
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
Installed SFP modules quantity 0
Installed SFP+ modules quantity 0
Gigabit Ethernet (copper) ports quantity 24
SFP+ module slots quantity 4
USB Type-A ports quantity 1
Console port RJ-45
Network
Networking standards IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G support Yes
Port mirroring Yes
Flow control support Yes
Link aggregation Yes
Broadcast storm control Yes
Rate limiting Yes
Spanning tree protocol Yes
Cable length detection Yes
Ethernet Ring Protection Switching (ERPS) Yes
VLAN support Yes
Virtual LAN features IP subnet–based VLAN, MAC address-based VLAN, Protocol-based VLAN, Stacked VLAN, VLAN mapping
Port trunking Yes
Data transmission
MAC address table 16000 entries
Switching capacity 128 Gbit/s
Forwarding rate 190.4 Mpps
Static route Yes
Jumbo frames support Yes
Jumbo frames 16000
Packet buffer memory 12 MB
Security
DHCP features DHCP server
Access Control List (ACL) Yes
IGMP snooping Yes
Security algorithms HTTPS
MAC address filtering Yes
SSH/SSL support Yes
Loop protection Yes
IP-MAC-Port binding Yes
Password protection Yes
Authentication type IEEE 802.1x
MAC address entries Dynamic MAC address entries, Static MAC address entries
Multicast features
Multicast support Yes
Protocols
GARP VLAN Registration Protocol (GVRP) Yes
Design
Rack mounting Yes
Product colour Black
LED indicators Fault, PoE, Power, Status, USB
International Protection (IP) code IP40
Performance
Telnet Yes
Dying Gasp Yes
Fanless Yes
Mean time between failures (MTBF) 200000 h
Power
Power source DC/PoE
Redundant power supply (RPS) support Yes
Power consumption (typical) 32 W
Power consumption (max) 402 W
Surge protection Yes
Surge protection voltage 6 kV
Power over Ethernet (PoE)
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) type supported PoE+, PoE++ (4PPoE)
Power over Ethernet (PoE) ports quantity 24
Power over Ethernet (PoE) power per port 90 W
Total Power over Ethernet (PoE) budget 370 W
Other features
Terminal block port Yes
Operational conditions
Operating temperature (T-T) -40 - 80 °C
Storage temperature (T-T) -40 - 85 °C
Operating relative humidity (H-H) 10 - 90%
Storage relative humidity (H-H) 5 - 95%
Weight & dimensions
Width 440 mm
Depth 280 mm
Height 45 mm
Weight 4.14 kg
Packaging content
Cables included LAN (RJ-45) to DB9
Quick start guide Yes
Rack mount kit Yes
Packaging data
Terminal block included Yes
Package width 525 mm
Package depth 390 mm
Package height 95 mm
Package weight 4.8 kg
Technical details
Pallet gross length 80 cm
Pallet gross width 120 cm
Certificates
Compliance certificates UKCA, Federal Communications Commission (FCC), RoHS, CE
Logistics data
Pallet gross height 177.6 cm
Country of origin China
Master (outer) case width 535 mm
Master (outer) case length 205 mm
Master (outer) case height 408 mm
Harmonized System (HS) code 851762
Master (outer) case gross weight 10.6 kg
Products per master (outer) case 2 pc(s)
