Out of Stock / Please Enquire ETA

KINGSTON

Kingston Technology 96GB, DDR5, 5600MT/s, ECC, Registered, DIMM, CL46, x80, 2RX4, 1.1V, 288-pin, 24Gbit

R96,980

incl. VAT: R111,527

Stock: Out of Stock / Please Enquire ETA
Brand: KINGSTON
Model: KSM56R46BD4PMI-96HMI
Weight: 0.04 kg
Dimensions: 16 × 5 × 1 cm
EAN: 740617340242
Product code: 762691

KINGSTON

Please Inquire

R96,980 incl. VAT: R111,527

We will email you when the product is back in stock.

Key features

PC/Server 96 GB DDR5 5600 MT/s
288-pin DIMM 1 x 96 GB
CAS latency: 46
1.1 V
ECC

Tags: kingston memory , kingston memor

Specifications

Features
Internal memory	96 GB
Memory layout (modules x size)	1 x 96 GB
Internal memory type	DDR5
Memory data transfer rate	5600 MT/s
Component for	PC/Server
Memory form factor	288-pin DIMM
ECC	Yes
On-Die ECC	Yes
CAS latency	46
Buffered memory type	Registered (buffered)
Memory ranking	2
Memory voltage	1.1 V
Module configuration	12288M x 80
Row cycle time	48 ns
Refresh row cycle time	295 ns
Row active time	32 ns
Row Precharge Time (TRP)	16
SPD profile	Yes
Programming power voltage (VPP)	1.8 V
Cooling type	Heatsink
Lead plating	Gold
JEDEC standard	Yes
Operational conditions
Operating temperature (T-T)	0 - 95 °C
Storage temperature (T-T)	-55 - 100 °C
Sustainability
Compliance certificates	RoHS
Sustainability compliance	Yes
Weight & dimensions
Width	133.3 mm
Height	31.2 mm
Other features
Doesn't contain	Halogen
